A.安装

1. Standard mounting.

1。标准安装。

a. Cut proper size hole in the top of the reservoir.

A.切适当大小的洞，储层的顶部。

b. Drill holes for studs within the proper bolt circle.

B.钻孔钉在适当的螺栓圆周。

c. Set the fi lter into the cutout hole and secure with

C.设置滤波器为切口孔和安全

proper size bolts, nuts and lock washers.

适当的尺寸的螺栓，螺母和垫圈。

d. Torque nuts in accordance with drawing.

D.扭矩螺母按图。

2. Mounting procedure using weld plate.

2。安装采用焊接板程序。

a. Rough cut proper size hole in the top of reservoir.

A.粗切适当大小的孔在油层顶部。

b. Weld the weld plate concentric to the rough cut

B.焊接的焊接板粗同心

hole.

孔。

c. Mount the fi lter onto the studs and secure with

C.安装滤波器上的螺柱和安全

nuts and lock washers.

螺母和锁紧垫圈。

d. Torque nuts in accordance with drawing.

D.扭矩螺母按图。

3. Utilize proper fi ttings.

3。利用适当的音响装置。

B. Start-Up

B.启动

1. Check for and eliminate leaks upon system start-up.

1。检查并消除泄漏在系统启动。

2. Check differential pressure indicator, if installed, to

2。如果安装止回阀的压差指示器，，以

monitor element condition.

监控单元的条件。

C. Service

C.服务

1. An element must be serviced when the indicator

1。一个元素必须维修时指示

indicates service is required.

指示服务是必需的。

NOTE: If the fi lter is not equipped with an indicator,

注意：如果滤波器是没有配备指示器，

the element should be serviced according to machine

该元件应该服务根据机

manufacturer’s instructions.

制造商的说明。
