HD069-789ARGO过滤器 11.4gpm 6.9g  V3.0520-13argo滤芯3 11.2lbs
HD069-769 ARGO过滤器13.2 gpm 7.6g  V3.0520-03 argo滤芯10.8 lbs
HD069-779 ARGO过滤器13.2 gpm 7.6g V3.0520-03 argo滤芯11.0 lbs
HD069-759 ARGO过滤器13.2 gpm 7.6g  V3.0520-03 argo滤芯11.0 lbs

过滤器的选择准则

For optimum efficiency and throughput, it is recommended

优化效率和吞吐量，it is recommended

that you select a filtration scheme based on

你选择了基于过滤方案

flow and differential pressure requirements.

流量和微分压力的要求。

To select your filter simply:

简：选择你的filter to

A. Select desired level of filtration (refer to Table 8 for

答：选择要过滤的表（refer to level of 8 for

reference).

参考）。

B. Select filter cartridge style and grade by referring to

B选择过滤器墨盒风格和品位by referring to

Tables 1, 2, 3, 4 and 5.

表1、2、3、4和5。

C. Confirm that the Profile II filter medium selected is

诉confirm that the Profile II过滤介质selected is

compatible with the fluid and the operating temperature.

符合流体和操作温度。

See Table 9.

见表9。

D. Determine the required number of 10 inch filter

D determine the required number of 10英寸过滤器

modules by dividing the system flow rate by the typical

模块的划分系统流速by the典型

flow rate per 10 inch module given in Table 6.

流动率每10英寸模块给出表6。

Calculate the clean pressure drop to verify that it is

计算清洁压力to verify that it is

acceptable.

可接受的。

E. Refer to Table 7 for ordering information on housings.

Refer to表。7 for订购信息器外壳。

Determine stacking array (number of cartridges

确定叠加阵列（number of cartridges

and length) of RF or AB series filter element(s) for

和长度）的金元素AB系列射频滤波器（S）。

selected housing.

选择住房。

F. Refer to Table 2 to complete ordering information

Refer to表F 2 to complete订购信息

for desired filter element(s).

for需要过滤元素（S）。

For example: You require a filter cartridge for 40 μm

例如：你需要的过滤器墨盒for 40μ

removal in an RF style. Your flow rate is 100 gpm.

Removal in an RF的风格。你的流动率是100加仑。

Therefore, from Table 6 you require approximately 6-

因此，你需要从表6约6

10, 10" filter modules (100 gpm divided by 15 gpm

10“过滤模块（100加仑divided by 15加仑

per 10" cartridge). From Table 7, you require a P04

每10”指南）。表7，你需要有P04

housing which can accept four 20" or 30" filter cartridges.

住房，可以接受“金炉20 30 cartridges”过滤器。

Four 20" filter cartridges (8, 10" filter modules)

“cartridges炉20滤波器（8，10”滤波器模块）

meet your requirements.

满足你的要求。

The part number for your filter cartridge would be:

the part number的过滤器墨盒将：

R2F400

r2f400

The part number stands for:

the part number stands for：

R: style-retrofit

R：风格的改进

2: 20" length

2：20”长度。

F400: 40 μm absolute rated, polypropylene Profile II

f400：40μm绝对评，聚丙烯Profile I
